- High productivity 36-inch dual light CIS scanner with RGB filters
- Secure scanning destinations Scan to secure sites, Mail, encrypted SSD and FTP servers
- Enhanced image quality Dual light scanner detects and adjusts to reduce wrinkles and creases
- Extensive processing and storage Adobe PS 64GB, 4GB Printer memory, 8GB scan mem included in 960GB SSD
Technology
Printing Method
PrecisionCore™ TFP print head
All-in-One Functions
Print, Scan, Copy
Ink Technology
Ultrachrome® XD3
Print
Colours Capacity
Photo Black [350ml, 700ml], Matte Black [350ml, 700ml], Cyan [350ml, 700ml], Yellow [350ml, 700ml], Magenta [350ml, 700ml], Red [350ml, 700ml]
Minimum Droplet Size (colour)
(CMY) 3,5 pl, (mk) 3,5 pl, (pk) 3,5 pl
Minimum line width
0,02 mm
Line accuracy
+/- 0,1
Print from
PC, MAC, Network, Mobile Device, USB, Cloud, Direct from Device
Printing Resolution
1.200 x 2.400 DPI
Printing Resolution – Speed
300 x 600 DPI
Paper / Media Handling
Paper Formats
A0, A1, A2 (42.0×59.4cm), A3 (29.7×42.0 cm), A4 (21.0×29.7 cm), 17″ (43.2 cm) Roll, 24″ (61.0 cm) Roll, 36″ (91.4 cm) Roll
Thickness
Single Sheet 0,1 mm, Roll 0,3 mm, Rigid board suppported
Compatible Paper Thickness
1,5 mm
Auto Take Up Reel
Yes
Roll Capacity – Diameter
Roll 1: 170 mm, Roll 2: 170 mm
Roll Capacity – Weight
Roll 1: 10.200 g, Roll 2: 10.200 g
Borderless printing on
20 inches, 10″ (25.4cm) Roll, 17″ (43.1cm) Roll, 24″ (60.9cm) Roll
General
Power consumption
75 Watt
Supply Voltage
AC 100 V – 240 V, 50 Hz – 60 Hz
Product dimensions
1.645 x 499 x 975 mm (Width x Depth x Height)
Product weight
150 kg
What’s in the box
Adobe PostScript 3, Ink set, Power cable, Roll Feed Spindle 36″, SureColor T-Series Printer/Scanner, User manual (CD), Warranty Documents
Optional extras
Cover Plus warranty extensions, SSD (Solid State Drive), NFC Card Reader (Server), NFC Card Reader (Serverless), Roll Feed Spindle 36″
Other Features
Emulations
ESC/P-R, PostScript 3, Adobe® Postscript 3®, PDF 1.7, HP-GL2, RTL
Optional storage
1TB SSD
Features
Touchscreen, Bluetooth, Direct print from USB, Driver Preview, Scan Preview, Auto Take up Reel, Nozzle Verification Technology
Interfaces
Hi-Speed USB – compatible with USB 2.0 specification, Ethernet Interface (1000 Base-T/ 100-Base TX/ 10-Base-T), Wireless LAN IEEE 802.11a/b/g/n/ac
Optional Software & Solutions
Epson Print Automate, Dinax Mirage, Epson Edge, Epson Cloud Solution PORT, Epson Print Layout, Epson LFP Accounting Tool, Epson Device Admin, Epson Edge Dashboard, Epson Print Admin, Epson Print Admin Serverless
Security
SNMP V3, IPSec, AES-256, Data storage Encryption, Data Encryption, WPA3, NFC – Card Authentication Reader, TMP (Trusted Platform Module), PIN code Release, Image Overwrite, User Authorisation, LDAP, IEEE802, SSL/TLS, Panel Admin Mode
Other
Warranty
24 months On-site service
LCD and Memory Cards
Panel
Type: Color, Touchscreen
Scan
Scanner
Standard
Maximum Precision
OR +/- 0,1 % of vector length (whichever is greater)
Destinations
SSD, USB (Memory device), Network Folder
Advanced document integration
Scan to FTP, Scan to Network folders, Scan to USB, USB Memory Device / Card
Output formats
JPEG, TIFF, multi-TIFF, PDF, PDF/A, PDF multi, Secured PDF
Scanner type
Contact image sensor (CIS)
Light Source
Dual LED (RGB)
Scan width
36″ (153mm to 914.4mm)
Scanning Speed
10 inch/sec ( Monochrome, 600 dpi; 4,5 inch/sec ( Colour, 200 dpi;
Maximum scan length
30,5 m
Copy
Reduction / Enlargement
25 % – 755 %
Maximum number of copies
99
