Sony UP-DR80MD A4 Digital Colour Roll Printer

R49 475 Incl VAT

UPC-R80MD Print Media A4 size

SKU: UP-DR80MD Categories: , Tags: ,

Features

Superb Print QualityStylish Design and Compact Size

The UP-DR80MD has a stylish design that fits perfectly with most medical environments. Its glossy white surface allows users to wipe it clean easily. Also, the compact body of the UP-DR80MD (approx. 317(W) x 207(H) x 425(D) mm (12 1/2 (W) x 8 1/8 (H) x 16 3/4 (D) inches) enables it to fit into both medical carts and constrained spaces.

Front Operation

The front-loading operation makes it easy to replace paper and ribbon, and allows the UP-DR80MD to be installed in even the tightest of spaces. This useful design feature also allows you to use the printer on-cart.

High-speed Printing

The UP-DR80MD operates at high speed. Printing an A4-sized image takes approximately 76 seconds

Wireless Printing Capability*

The optional UPA-WU10 Wireless Print System allows cable-free connection between the UP-DR80MD and surgical endoscopes, ultrasound systems, and other hospital imaging modalities. This is ideal for busy clinical environments, where modalities are constantly being moved between different OR and treatment rooms. This all-in-one wireless printing solution also resolves the problem of limited space on medical carts, allowing connection between a medical imaging modality and an ‘off-cart’ printer without requiring a lengthy USB cable.

* This function is available to Sony digital printers with USB 5V type A Output port. For more information regarding the compatibility, please contact your nearest Sony office or an authorised dealer.

Compliance with medical standards

This product is distributed to the US and EU as a medical device and satisfies product safety standards (e.g. IEC 60601-1).

For more details, please contact your nearest Sony sales office or an authorised dealer.

Printing Method
Dye sublimation printing
Resolution
301 dpi
Gradations
8 bits (256 levels) processing each for yellow, magenta and cyan
Effective Print Pixels
A4 size UPC-R80MD: 3400 x 2392 dots
Letter size UPC-R81MD: 3192 x 2464 dots
Print Area
A4 size: 287 x 202 mm (11 1/4 x 8 inches)
Letter size: 269 x 208 mm (10 5/8 x 8 1/4 inches)
Printing Time
A4 size: Approx. 76 sec
Letter size: Approx. 72 sec
Interface
Hi-Speed USB (USB 3.0)
Paper Tray Capacity
50 sheets
Power Requirements
AC 100 to 240 V, 50/60 Hz
Input Current
3.4 to 1.4 A
Output current
0.5A/5V (USB 3.0)
Operating Temperature
5 °C to 35 °C
Operating Humidity
20% to 80% (no condensation allowed)
Storage and Transport Temperature
-20 °C to 60 °C
Storage and Transport Humidity
20% to 80% (no condensation allowed)
Dimensions
Approx. 317(W) x 207(H) x 425(D) mm
(12 1/2 (W) x 8 1/8 (H) x 16 3/4 (D) inches)
Mass
Approx. 11.5 kg (25.3 lbs)

UP-DR80MD
